Keychron Q1 HE vs Q1 Max: Pick by How You Type, Not by Spec Sheet

The Q1 HE and the Q1 Max share one 75% layout and the same 327.5 mm footprint, and the switch under each key is the difference. If you set keys up for games and want to choose how far a press travels before it counts, pick the Q1 HE. If you want a bump you can feel and a choice of three switches for all-day typing, pick the Q1 Max.

Specs below come from our product pages, checked on October 27, 2026. We did not run our own tests for this guide.

What is the same on both Q1 boards?

Short answer: The footprint, layout, connection types, polling rate, battery capacity and software. The switch, keycaps, plate, case height, Bluetooth version and battery life differ.

Both boards share these specs:

• Layout: 75% ANSI with a knob, 145 x 327.5 mm.
• Case: 6063 aluminum with a double-gasket design and screw-in PCB stabilizers.
• Connection: a 2.4 GHz receiver, Bluetooth to three devices, or a USB-C cable.
• Polling rate: 1000 Hz on the receiver and the cable, 90 Hz on Bluetooth.
• Software: QMK firmware and the Keychron Launcher web app, opened in Chrome, Opera or Edge with the cable plugged in.

The polling rate is how often the keyboard reports to the computer. At 1000 Hz both boards report once every millisecond.

You are choosing a switch, and everything that comes with it.

How does the switch change the way you type?

Short answer: On the Q1 HE a sensor reads how far you press, and you set the trigger depth per key. On the Q1 Max the switch registers at a fixed point.

A mechanical switch has two metal contacts. The key registers when they touch, at a point the switch design fixes. For the Gateron Jupiter switches on the Q1 Max, all three options register at about 2 mm of travel (rated 2.0 mm, plus or minus 0.6 mm).

A magnetic switch has no contacts. A sensor under the key reads how far the stem has moved, in 0.1 mm steps on the Q1 HE. You set the actuation point for each key anywhere from 0.2 to 3.8 mm in Keychron Launcher. With Rapid Trigger on, a key resets after a release distance you set, instead of at one fixed point, so you can repeat a press without lifting the key all the way. Dynamic Keystrokes assigns up to four actions to one key by press depth.

Frames from our Q1 HE actuation animation. The two frames show 1 mm and 3.5 mm; the Q1 HE accepts any point from 0.2 to 3.8 mm in 0.1 mm steps.

The Nebula switch on the Q1 HE has no tactile bump at any setting; a magnetic switch feels much like a linear mechanical switch. If a bump matters to you, that decision comes before the actuation point, and it points to the Q1 Max. Our magnetic keyboards explained post covers how the sensor reads a press in more detail.

Check: Do you want to change where a key triggers, or do you want to feel where it triggers? The first is the Q1 HE, the second is the Q1 Max.

Which specs differ between the two Q1 boards?

Short answer: Switch, keycap profile, plate, battery life and the option list.

Both batteries are 4000 mAh; with the backlight off, the Q1 Max lists 180 hours against 100 hours. Weight is about 1.7 kg on both (1735 g and 1724 g, each plus or minus 10 g), so treat it as the same.

Keychron Q1 HE: Best for games and a trigger point you set yourself

View the Q1 HE on keychron.com →

Short answer: Pick the Q1 HE if you want to tune each key for the game you play.

Our Q1 HE comes with the Gateron Double-Rail Magnetic Nebula Switch under every key. Set the letters you move with to a short actuation point, 0.8 mm or 1.0 mm, and they trigger on a shallower press. Turn Rapid Trigger on for those keys and each one resets after the release distance you set. Keys you type with can sit at a deeper point, so a brush of the finger no longer counts.

All of this lives in the HE Mode of Keychron Launcher. You press the keys you want to change, or click them on the virtual keyboard, then slide the actuation distance bar or type a value. Our HE mode guide walks through each setting. For hot-swapping, the board takes the Gateron Double-Rail Magnetic Switch, sold in Dawn, Nebula and Aurora, so you can swap in another Double-Rail option later.

Pick: Carbon Black or Shell White as the Fully Assembled Knob. Barebone Knob ships without switches or keycaps; pick it if you will add Gateron Double-Rail Magnetic Switches and keycaps yourself.

Keychron Q1 Max: Best for all-day typing with a switch you choose

View the Q1 Max on keychron.com →

Short answer: Pick the Q1 Max if you type more than you play and want to feel the switch.

On the Q1 Max, the mechanical Q1, you choose one of three Gateron Jupiter switches. Red is linear, rated 45 gf, a light and smooth press. Brown is tactile, rated 55 gf, with a small bump; our red switch vs brown switch guide calls it the versatile pick for typing and gaming. Banana is tactile, rated 59 gf, with an earlier and stronger bump, a two-stage spring and 3.4 mm of total travel against 4.0 mm on the other two.

The KSA double-shot PBT keycaps suit standard typing. The Side-Printed version uses OSA side-printed keycaps that let the backlight shine through. Under the keys sit a PC plate and IXPE, PET and latex sound layers.

Every switch on the Q1 Max is hot-swappable with almost all 3-pin and 5-pin MX-style mechanical switches, without soldering.

Pick: Fully Assembled Knob with Gateron Jupiter Brown for typing and games on one board, Gateron Jupiter Red for a light press, or Gateron Jupiter Banana for a stronger bump. Choose Fully Assembled Knob (Side-Printed Keycaps) for shine-through legends. Purple comes only as the Fully Assembled Knob; Carbon Black and Shell White come in every type.

Keychron Q1 HE 8K: Best for competitive play at a wired desk

View the Q1 HE 8K on keychron.com →

Short answer: Pick the Q1 HE 8K if you want the magnetic features with an 8000 Hz polling rate.

Our Q1 HE 8K is the wired, 8000 Hz magnetic Q1, with its own switch. It reports at up to 8000 Hz over the cable, eight times per millisecond, and a three-position switch on the board steps through 1000, 2000 and 8000 Hz. Its Keychron Ultra-fast Lime Magnetic Switch sets the actuation point from 0.1 to 3.35 mm in 0.01 mm steps.

Check these differences from the other two boards before you buy. It connects by cable only. Its software is the Keychron Launcher web app; QMK firmware is not in its software line. Hot-swap covers the Keychron Ultra-fast Lime Magnetic Switch, and the fully assembled board weighs 1860 g.

Pick: Fully Assembled, the only type, in Black or White, with the Keychron Ultra-fast Lime Magnetic Switch.

Which Q1 is the best for you?

Short answer: Pick by what you want each key to do, then by whether you want to feel a bump.

1. Do you want to set where a key triggers, or use Rapid Trigger? If yes, pick the Q1 HE. If you also want 8000 Hz on a cable, pick the Q1 HE 8K.
2. Do you want a tactile bump, or a choice of three switches? If yes, pick the Q1 Max: Gateron Jupiter Brown or Gateron Jupiter Banana for the bump, Gateron Jupiter Red for a linear press.
3. Will you try other mechanical switches later? Pick the Q1 Max; it takes almost all 3-pin and 5-pin MX-style switches.

If you need a number pad, our Q1 Max vs Q5 Max vs Q6 Max guide compares the 96% and full-size Max boards.

Frequently asked questions

Is the Q1 HE good for daily typing?

Yes. The Nebula switch on the Q1 HE has no bump, and the keycaps are double-shot PBT like the other two boards here. Set the letter keys to a deeper actuation point and a light touch no longer counts as a press.

Can I use the Q1 Max for gaming?

Yes. On the receiver and the cable, both boards report at 1000 Hz. Many gamers favor a linear switch for FPS games, which on the Q1 Max is Gateron Jupiter Red. If you want a trigger point you set per key, that is the Q1 HE.

Do the Q1 HE and Q1 Max work with a Mac?

Yes. Each board has a system toggle for macOS and Windows and saves one layout for each system. The fully assembled versions come with Mac and Windows keycaps, and Keychron Launcher runs in Chrome, Opera or Edge on macOS, Windows and Linux.

Shop the products in this guide

References & Citations

• Q1 HE layout, size, connection, polling rate, actuation range, Rapid Trigger, Dynamic Keystrokes, hot-swap range, keycaps, battery, weight, options and colors. (Keychron Q1 HE product page)
• Q1 Max layout, size, connection, polling rate, switches, hot-swap range, keycaps, plate, sound layers, battery, weight, options and colors. (Keychron Q1 Max product page)
• Q1 HE 8K wired 8000 Hz polling rate, three-position polling switch, Lime switch actuation range, Last Key Priority, Snap Click, hot-swap range and weight. (Keychron Q1 HE 8K product page)
• Gateron Jupiter Red, Brown and Banana: switch type, operation force, pre-travel, total travel and the Banana two-stage spring. (Gateron Jupiter Switch Set)
• Gateron Double-Rail Magnetic Switch options (Dawn, Nebula, Aurora), 0.1 mm sensitivity and compatible keyboards. (Gateron Double-Rail Magnetic Switch)
• How to set the actuation distance and Rapid Trigger per key in Keychron Launcher. (How to use HE mode on Keychron Launcher)
• How a magnetic switch reads a keypress and why the feel still comes from the spring and stem. (Magnetic keyboards explained)
